Sandvik Coromant R175.32-5047M Rectangular shank to cartridge adaptor
R 6 456,10
inc. vat
In stock
SKU
5742468
Rectangular shank to cartridge adaptor
Reliable nationwide shipping
Delivery in 4 - 5 days
Rectangular shank to cartridge adaptor
| KAP - Kappa (z-axis Rot) | 0deg |
|---|---|
| LF - Functional Length | 275mm |
| WT - Weight Of Item | 4.544kg |
| OAL - Overall Length | 275mm |
| OHX - Maximum Overhang | 200mm |
| LSC - Clamping Length | 200mm |
| BAWS - Workpiece Side Body Angle | 0deg |
| OHN - Minimum Overhang | 75mm |
| WF - Functional Width | 44mm |
| HF - Functional Height | 44mm |
| H - Shank Height | 50mm |
| LPR - Protruding Length | 275mm |
| B - Shank Width | 47mm |
| ORDCODE | R175.32-5047M |
| ADINTMS - Adaptive Interface Machine Direction | M_VKT01_A5047_1 |
| ADINTWS - Adaptive Interface Workpiece Direction | W_CRTRW_C023R_1 |
| CNSC - Coolant Entry Style Code | 0 |
| CXSC - Coolant Exit Style Code | 0 |
| BMC - Body Material Code | 1 |
| CHANGEDATE | 2022-06-08 20:18:00.000 |
| Hand | R |
| DPC - Damping Property | False |
| NROTF - Non Rotating Functionality | True |
| RTOF - Rotating Functionality | False |
